Design Master Electrical 8.6.23

Released September 19, 2022.

• Fixed recurring panel instance AIC rating to allow non-numeric values.
• Updated voltage drop calculations to better account for junction boxes on circuits without homeruns.
• Added support for additional breaker curves.
• Fixed crash related to sequential feeder IDs.
• Prevent crash when attempting to create a slide that includes a parenthesis in the name.
• Fixed crash in the "Edit Multiple Recurring Panel Instances" command.
• Fixed crash when using a specific layer for photometric contours.
• Fixed recurring panel instance homeruns to update automatically when modified.
• Fixed error when starting a new project related to loading schedule settings.
• Fixed errors in BricsCAD related to selecting folders.
• Fixed "N/A" NEMA type to not be displayed on the drawing.
